UniFI Switch Enterprise XG24

Name: UniFI Switch Enterprise XG24
SKU: 622
Price: 33450.00 THB
Availability: InStock

33,450.00฿

UniFi Switch Enterprise XG 24 Layer 3 Switch Device Type (24) 10GbE RJ45 ports and 25G SFP28 ports

Managed with the UniFi Network application: Version 6.1.67 and later

หมวดหมู่: Ubiquiti, Ubiquiti Switch

Mechanical
Dimensions	442 x 44 x 285 mm (17.4 x 1.7 x 11.2″)
Weight	Without Mount: 4.47 kg (9.85 lb) With Mount: 4.57 kg (11.02 lb)
Enclosure Materials	SGCC Steel
Mount Material	SGCC Steel
Hardware
Total Non-Blocking Throughput	290 Gbps
Switching Capacity	580 Gbps
Forwarding Rate	431.52 Mpps
Max. Power Consumption	100W
Power Method	(1) Universal AC input: 100-240VAC, 2A Max., 50/60 Hz (1) USP-RPS DC input: 11.5VDC, 8.7A
Power Supply	AC/DC, Internal, 100W
Management Interface	Ethernet In-Band
Networking Interfaces	(24) 100/1,000/2,500/5,000/10,000 Mbps RJ45 Ethernet
SFP28 Interfaces	(2) 1/10/25 Gbps SFP28* *The two SFP28 ports don’t support mixed speed at 25Gbps mode. Once one of the SFP28 ports is con gured at 25Gbps mode, the others will be limited at 25Gbps too. The SFP28 ports only support mixed speed when all ports are at 1Gbps or 10Gbps.
Services	SMB Layer 3 Gigabit Ethernet Switch
ESD/EMP Protection	Air: ± 16 kV, Contact: ± 12 kV
LCM Display	1.3″ Touchscreen Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted
Button	Factory Reset
LEDs	White: Link or Activity
Operating Temperature	-5 to 40° C (23 to 104° F)
Operating Humidity	10 – 95% Noncondensing
Certifications	CE, FCC, IC
Download	Datasheet
Warranty	1 year
