Ubiquiti U-POE-AF

790.00฿

Ubiquiti U-POE-AF อุปกรณ์ PoE Injector แบบ Gigabit (10/100/1000Mbps) มาพร้อมมาตรฐานการจ่ายไฟแบบ IEEE802.3af

Line ID: @krsystems

หมวดหมู่: Accessories, Ubiquiti

คำอธิบาย
บทวิจารณ์ (0)

U-POE-AF
Dimensions	86 x 46 x 33 mm (3.39 x 1.81 x 1.30″)
Weight	100 g (3.53 oz)
Output Voltage	48VDC @ 0.32A
LAN Activity Indicator	No
Gigabit LAN Port	Yes
Remote Reset Capability	Yes
Reset Button	No
Rated Voltage	100-240VAC @ 50/60Hz
Input Current	500mA @ 90VAC
Inrush Current	<100A Peak @ 25°C
Efficiency	0.8425
Output Ripple	200mV p-p
Switching Frequency	65 kHz
Line Regulation	≤ 3%
Load Regulation	≤ 5%
2-Pair Powering	Pins 4, 5 ( ) and Pins 7, 8 (-)
4-Pair Powering	–
Operating Temperature	0 to 40° C (32 to 104° F)
Storage Temperature	-30 to 70°C (-22 to 158° F)
Operating Humidity	5 to 90% Noncondensing
AC Connector	IEC-320 C6
Data IN / POE	RJ45 Shielded Socket
Surge Protection	Difference and Common Mode
Clamping Protection	11V Data, 60V Power
Max. Surge Discharge	1500A (8/20 μs) Power
Peak Pulse Current	36A (10/1000 μs) Data
Shunt Capacitance	<5 pF data
Response Time	<1 ns
Certifications	CE, FCC, IC, UL
