-6%
UniFi Switch 16 POE
Original price was: 15,490.00฿.14,490.00฿Current price is: 14,490.00฿.
- (8) Gigabit RJ45 ports with 802.3af/at
- (8) Gigabit RJ45 ports
- (2) 1G SFP ports
- PoE Power Budget 42W
- Switching Capacity 36 Gbps
- Forwarding Rate 26.78 Mpps
UniFi Switch 16 PoE Gen2
The USW-16-POE is a configurable Layer 2 Gigabit Switch, equipped with sixteen Gigabit Ethernet ports, as well as eight auto-sensing 802.3at PoE ports and two SFP ports. SOHO
UniFi Switch 16 PoE Gen2 offers a suite of protocols and advanced Layer 2 switching features that include modes of operation (switching, mirroring, or aggregate) per port. UniFi network controllers and mobile apps allow administrators to configure and monitor all switch properties.
- (8) Gigabit RJ45 ports with 802.3af/at
- (8) Gigabit RJ45 ports
- (2) 1G SFP ports
- 1U Rackmountable
| Brand | Ubiquiti |
| Model | USW-16-POE |
| Dimensions (Without Mounting Plate) | 442.4 x 200 x 43.7 mm (17.42 x 7.87 x 1.72″) |
| Weight With Brackets |
2.80 kg (6.17 lb) 2.89 kg (6.37 lb) |
| Interfaces Networking Management |
(16) 10/100/1000 RJ45 Ports (2) 1G SFP Ethernet Ports Ethernet In-Band |
| Total Non-Blocking Throughput |
18 Gbps |
| Switching Capacity | 36 Gbps |
| Forwarding Rate | 26.78 Mpps |
| Power Method | 100-240VAC, 50/60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 60W |
| Voltage Range | 100 to 240VAC |
| Max Power Consumption (Excluding PoE Output) |
18W |
| LEDs System RJ45 Data Ports SFP Data Ports |
Status PoE; Speed/Link/Activity Link/Activity |
| ESD/EMP Protection | Air: ± 16 kV, Contact: ± 12 kV |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | 10 – 90% Noncondensing |
| Certifications | CE, FCC, IC |
| PoE | |
|---|---|
| Total Available PoE | 42W |
| PoE Interfaces Ports 1-8 |
POE IEEE 802.3af/at (pins 1, 2 ; 3, 6-) |
| Max. PoE Wattage per Port by PSE 802.3at |
32W |
| Voltage Range 802.3af Mode 802.3at Mode |
44-57V 50-57V |
| Warranty | 1 year |
| Download | Quick Start Guide Datasheet |
